Mission to objective to capability to work type to work item.

The chain that gives every piece of work a line of sight to the mission, the seats in three tiers, KPIs as stop conditions, and the rule that agents go first and people accept.

The KTP mechanism

A ≤ E, read from the top: authority for a work item is derived from the mission's line of sight, never asserted by the worker.

KTP bounds an action by the environment it runs in. The Mission Join bounds it from above as well: a work item serves a work type, which serves a capability, which serves an objective, which serves the mission. If that line of sight cannot be derived, the work has no standing. An objective with no measure reads unknown, never met, and risk is never averaged across the chain.

The working form, from the workbook

Node and edge types for the chain, three seat tiers (mission, business, IT), the rules and gates the join enforces, KPIs whose experience readings are agent stop conditions, and the “agents first” rule: agents execute, humans accept. The worked example's mission, seats, capabilities and KPI rows stay with it; the structure and the column designs travel.

Where it is written down

OTCS-0019 Requirement profilesDRAFT · in deliberation · earliest decision 2026-12-11
KG-22 to KG-26 on the knowledge-graph page
Work types

1 of 5MissionWhat the organization is for; one per join.
has-objectiveEvery objective belongs to one Mission.KG-25 · an objective has an owner seat and a measure
2 of 5ObjectiveOwned by a seat, with a measure. No measure: unknown, never met.
needsAn objective names the capabilities it depends on.KG-22 · line of sight is derived from these edges
3 of 5CapabilityWhat the business can do; relies on IT services.
servesA work type serves at least one capability.KG-24 · a work type with no serves edge is a finding
4 of 5Work typeOne object, one verb, and what must be able to refuse it.
instance-ofEvery work item is one instance of one work type.KG-22 · never an edge straight from a work item to an objective
5 of 5Work itemOne instance of one work type, acting on a service, host, identity or case.

The KPI loop

A KPI measures an objective and is observed by a work type; it is evidence for the work whose effect it informs, and a breach is refusal input to continuation for agent work on the same venue or service (KG-26). A KPI never holds the verifier role.

Read in KTP's terms

Authority flows down the chain and is derived at every step; a work item never asserts its own line of sight. That is A ≤ E read from the top: the mission is the environment every piece of work must fit inside.

Acequia, Inc. is an invented organization. These pages present a working design, not deployment results; its contracted stages and change freezes are illustrative. The sections below mirror the Governed Autonomy workbook (v0.50): its columns, rules, invariants and catalogs, as written, with the worked example's organization named as it is there. The deployment's own rows, parties, contract identifiers and configuration stay with the deployment; where a table's rows stay, its columns are shown.

0111. The Mission Join — node typesworkbook tab 07 · Knowledge graph

¶
Mission
Statement, owner (PTY::), mission horizon. One per organization.
¶
Objective
Statement, owner seat, measure. A missing measure is unknown, not met.
¶
Capability
What the organization must be able to do. Owner seat. Not a department and not a system.
¶
Value stream
Stakeholder, outcome, ordered stages. Each stage is enabled by capabilities.
¶
Work type
A catalog : maps_to, roles, ceiling, refusal points.
¶
Work item
Kind (case, change, request, problem, release, deliverable, …), spine, state, work type.
¶
Outer seat
Tier (mission, business, it), name, source. Not a party.
¶
KPI
Name, classes, per-class macro/meso/micro, crosswalk, status (from deck, proposed, unmapped). Open list.

0211. The Mission Join — edge typesworkbook tab 07 · Knowledge graph

¶
has-objective
Mission
To
Objective
Rule
Every objective belongs to one Mission.
¶
needs
Objective
To
Capability
Rule
An objective names the capabilities it depends on.
¶
enabled-by
Value stream
To
Capability
Rule
Per stage. A capability can enable stages in many value streams.
¶
supported-by
Capability
To
Service
Rule
The IT services a capability relies on.
¶
serves
Work type
To
Capability
Rule
A serves at least one capability (KG-24).
¶
instance-of
Work item
To
Work type
Rule
Every work item is one instance of one work type.
¶
acts-on
Work item
To
Service, Host, Identity, Venue, Journey, or Case
Rule
The objects the work changes.
¶
holds-role
Outer seat
To
Work type
Rule
Carries the role. Not populated: the is guidance, and roles are assigned where it is deployed.
¶
measures
KPI
To
Objective
Rule
A KPI measures one or more objectives. Evidence Integrity and Ambient Breach measure all of them.
¶
observed-by
KPI
To
Work type
Rule
The observe-type work that produces the reading.
¶
evidence-for
KPI
To
Work type
Rule
The work whose effect the KPI informs, or whose continuation it can stop.
¶
occupies
Party
To
Outer seat
Rule
Reused from the Case Join. A party can occupy seats at both levels. A seat is not a party.
¶
nested-in
Case Join
To
Mission Join
Rule
Reused (KG-17). The Case Join occupies one IT-tier seat (SEAT::IT.CASE) as a member; its own six seats are unchanged.

0311. The Mission Join — seat tiersworkbook tab 07 · Knowledge graph

¶
Mission
MSN
Holds
The Mission, the objectives, and the authority over them.
Source rule
A ruling by the organization that owns the Mission.
¶
Business
BUS
Holds
The departments and partners that deliver the Mission's outcomes.
Source rule
The party register or a recorded ruling.
¶
IT
IT
Holds
Every IT group, and the nested Case Join as one member.
Source rule
The party register or a recorded ruling.

0411. The Mission Join — rulesworkbook tab 07 · Knowledge graph

Line of sight is derived. No measure reads unknown, never met. Risk is never averaged.

¶
Parent and child
The is the parent. The Case Join holds one nested-in edge to it and keeps its own IDs. The refers to a Case as GRAPH::case-join/CASE::<id>.
Invariant
KG-17, KG-18
¶
Six seats stay six
The Case Join keeps exactly six seats. The tiers are seats of the Mission Join, not new seats of the Case Join.
Invariant
KG-2
¶
Line of sight is derived
Work item → → capability → objective → Mission. The path is computed from those edges. Nobody writes an edge from a work item to an objective by hand.
Invariant
KG-22
¶
Every seat cites a source
A seat exists only with a party-register row or a recorded ruling.
Invariant
KG-23
¶
Work serves the business
A work type serves at least one capability. A work type that serves none is a finding, not a gap to hide.
Invariant
KG-24
¶
Objectives are measured
An objective has an owner seat and a measure. With no measure, its state is unknown, never met.
Invariant
KG-25
¶
Seats are roles, not boxes
A seat holds roles in . It is not an organization-chart box, and partitioning still never follows the chart (§21).
Invariant
§21
¶
Agents execute, humans verify and accept
Agents carry out most work. A KPI is evidence for the human effect and never holds that role; the is always a person.
Invariant
Catalog §4
¶
A breach can stop an agent
A KPI breach is refusal input to continuation for agent work on the same venue or service.
Invariant
KG-26
¶
Evidence Integrity gates every objective
An objective reads met only when its Evidence Integrity KPIs are healthy. Missing evidence is unknown, never green. Risk is never averaged.
Invariant
KG-25, KG-26
¶
One spine per kind
Each work-item kind has one spine, taken from the framework that defines it. The Case spine, states 0–7, is unchanged.
Invariant
ASM-09

0511. The Mission Join — gatesworkbook tab 07 · Knowledge graph

¶
Line of sight complete
A work item has no derived path to a Mission.
Invariant
KG-22
¶
Line of sight not asserted
An edge runs from a work item straight to an objective or a Mission.
Invariant
KG-22
¶
Seat has a source
An outer seat has no party-register row and no recorded ruling.
Invariant
KG-23
¶
Work type serves a capability
A has no serves edge.
Invariant
KG-24
¶
Objective has owner and measure
An objective has no owner seat, or reports met with no measure.
Invariant
KG-25
¶
KPI has a class and honest state
A KPI has no class, or reports green with missing evidence.
Invariant
KG-26
¶
Case Join keeps six seats
The nested Case Join has a seat other than CYB, ITO, APO, GOV, REG, or CMP.
Invariant
KG-2

06KPIs as stop conditions: the column designworkbook tab 08 · Mission Join

A KPI is not a scoreboard. Its experience reading is a stop condition an agent must honor.

The columns · the rows stay with the deployment

KPI
Name
Classes
Objectives
Observed by
Evidence for
Agent stop
Crosswalk

077. Agents firstworkbook tab 08 · Mission Join

The executor is a machine by default; a person accepts the class of work and owns the residual risk.

¶
Agents execute
Agents carry out most of the work. A is human-only only where it says so (for example risk.accept, bank_account.change).
¶
Humans verify and accept
A KPI is evidence the human effect reads. A KPI never holds the role, and a machine never holds the role.
¶
A breach can stop an agent
An Experience KPI breaching for a venue is refusal input to continuation for agent work on that venue (can_refuse: continuation).
¶
Unknown is not green
A KPI with missing evidence reads unknown. Risk KPIs are never averaged. An objective reads met only when its Evidence Integrity KPIs are healthy.

08Traces: objective to KPI to work (the column design)workbook tab 08 · Mission Join

The columns · the rows stay with the deployment

Trace
Objective
KPI
Observed by
Work
How agents and people share it

09Party is not seatworkbook tab 11 · Party register

What this is for. Who sits at the table, and which role they play on the case.

The kinds of work on the case do not grow. The list of organizations can. How to use it. Find a player by name. The seat a player occupies is recorded apart from who they are.

Acequia is the customer and mission owner. The Acequia organizing unit owns delivery, and Acequia departments sit beneath it. Providers remain separate parties. Party identity is separate from the six join seats: Cyber Security (CYB), IT Operations (ITO), Application Operations (APO), Governance (GOV), Regulatory (REG), and Compliance (CMP).

1. Players — Acequia 0001, Acequia organizing unit 0002, providers, then Acequia departments from 0100

¶
PTY::0001
0001
Status · active
7 fields
Main name
Acequia, Inc.
Second name
Mission owner
Kind
organization
Primary join seat
REG
Parent
—
Graph org
org:acequia
Note
Mission and policy authority. Occupies REG.
¶
PTY::0002
0002
Status · active
7 fields
Main name
Acequia organizing unit
Second name
Organizing unit
Kind
organization
Primary join seat
GOV
Parent
—
Graph org
org:acequia-organizing-unit
Note
Organizing authority. Acequia departments start at PTY::0100.
¶
PTY::0003
0003
Status · active
7 fields
Main name
Media Provider
Second name
Media Provider
Kind
organization
Primary join seat
ITO
Parent
—
Graph org
org:media-provider
Note
Media estate. Observe and hand off; not another .
¶
PTY::0004
0004
Status · active
7 fields
Main name
Operating Provider
Second name
Operating Provider
Kind
partner
Primary join seat
CYB
Parent
—
Graph org
org:operating-provider
Note
Operating authority and playbook owner.
¶
PTY::0005
0005
Status · active
7 fields
Main name
Data Analytics Provider
Second name
Data Analytics Provider
Kind
partner
Primary join seat
CYB
Parent
PTY::0008
Graph org
org:data-analytics-provider
Note
Data analytics platform provider.
¶
PTY::0006
0006
Status · active
7 fields
Main name
Network Service Provider 1
Second name
Network Provider 1
Kind
partner
Primary join seat
ITO
Parent
—
Graph org
org:network-provider-1
Note
Transport provider. Network Service Provider 2 is subordinate.
¶
PTY::0007
0007
Status · active
7 fields
Main name
Network Service Provider 2
Second name
Network Provider 2
Kind
partner
Primary join seat
ITO
Parent
PTY::0006
Graph org
org:network-provider-2
Note
Network service provider. Parent is Network Service Provider 1.
¶
PTY::0008
0008
Status · active
7 fields
Main name
Network Platform Provider
Second name
Network Platform Provider
Kind
partner
Primary join seat
ITO
Parent
—
Graph org
org:network-platform-provider
Note
Network platform provider. Data Analytics Provider is subordinate.
¶
PTY::0009
0009
Status · active
7 fields
Main name
Cloud Security Provider
Second name
Cloud Security Provider
Kind
partner
Primary join seat
CYB
Parent
PTY::0004
Graph org
org:cloud-security-provider
Note
Cloud security provider. Parent is Operating Provider.
¶
PTY::0100
0100
Status · active
7 fields
Main name
Acequia department 1
Second name
PMO
Kind
department
Primary join seat
GOV
Parent
PTY::0002
Graph org
org:acequia-dept-1
Note
Acequia department.
¶
PTY::0101
0101
Status · active
7 fields
Main name
Acequia department 2
Second name
Telecom
Kind
department
Primary join seat
ITO
Parent
PTY::0002
Graph org
org:acequia-dept-2
Note
Acequia department. Network design owner label.
¶
PTY::0102
0102
Status · active
7 fields
Main name
Acequia department 3
Second name
ITSM
Kind
department
Primary join seat
ITO
Parent
PTY::0002
Graph org
org:acequia-dept-3
Note
Acequia department. Service-management owner label.
¶
PTY::0103
0103
Status · active
7 fields
Main name
Acequia department 4
Second name
Cybersecurity
Kind
department
Primary join seat
CYB
Parent
PTY::0002
Graph org
org:acequia-dept-4
Note
Acequia department. Cybersecurity owner label.
¶
PTY::0104
0104
Status · active
7 fields
Main name
Acequia department 5
Second name
Venue
Kind
department
Primary join seat
ITO
Parent
PTY::0002
Graph org
org:acequia-dept-5
Note
Acequia department. Venue-technology owner label.

Continue · Run it

How to cite

APA 7th ed.

Perkins, C. (2026). Mission to objective to capability to work type to work item. Kinetic Trust Protocol. https://kinetic-trust-protocol.net/governed-autonomy/mission-join

Plain text

Chris Perkins, "Mission to objective to capability to work type to work item," Kinetic Trust Protocol, https://kinetic-trust-protocol.net/governed-autonomy/mission-join.

Page created 28 October 2026 · last modified 2026-10-27
